Image MapsIt's been more than seven years since I first published my CSS Image Maps article/tutorial. I've received numerous emails from people thanking me for showing how it's done that I thought I'd update it to make it more relevant to the CSS capabilities of today's modern browsers.

Today's solution requires less code, needs no images (apart from the one you're using for the map, no doubt) and offers some nice sprinkles of CSS3 transitions, including fading and animating the "info bubble" when hovering over an annotated area on the image.

I took the existing CSS, cleaned it up to make it a little more modular (and less DRY) and, as always, have provided a working example. Below is the required code to create your own CSS3 Image Map:

Advertisement

HTML:


            <dl id="inTheStudioMap">
                <dt class="title">In The Studio...</dt>
                <dt id="screen">1. Screen</dt>
                <dd id="screenDef"><a href="#"><span>Ableton, FTW!</span></a></dd>
                <dt id="synth">2. Virus TI</dt>
                <dd id="synthDef"><a href="#"><span>Sweet sounds from the Virus</span></a></dd>
                <dt id="snacks">3. Snacks</dt>
                <dd id="snacksDef"><a href="#"><span>Mmmmm, snacks.</span></a></dd>
            </dl>




CSS:


            /* image map container (and actual image) */
            dl#inTheStudioMap{
                margin: 0;
                padding: 0;
                background: transparent url(studio.jpg) top left no-repeat;
                height: 299px;
                width: 400px;
                position: relative;
                box-shadow: 0 0 5px rgba( 0, 0, 0, 0.5 );
                border: 5px solid #fff;
            }

            dd a{
                position: absolute;
                outline: none;
                text-decoration: none;
                border: 1px solid #FFFCE6;
                background: rgba( 255, 255, 191, 0.4 );
                text-shadow: 0 1px 0 rgba( 255, 255, 255, 0.9 );

                -webkit-transition: background 1s ease-in-out, border 1s ease-in-out;
                -moz-transition: background 1s ease-in-out, border 1s ease-in-out;
                -o-transition: background 1s ease-in-out, border 1s ease-in-out;
                -ms-transition: background 1s ease-in-out, border 1s ease-in-out;
                transition: background 1s ease-in-out, border 1s ease-in-out;
            }

            dd a:hover{
                background: rgba( 255, 255, 255, 0 );
                border: 1px solid transparent;
            }

            dd a:active{
                outline: none;
                -moz-outline: none;
            }

            dd a span{
                opacity: 0;
                visibility: hidden;
                position: absolute;
                left: -1px;
                top: 0;
                height: 20px;
                line-height: 20px;
                text-indent: 0;
                vertical-align: top;
                background-color: #F4F4F4;
                font-weight: bold;
                color: #333;
                border: 1px solid #F4F4F4;
                margin: 0;
                padding: 5px;
                white-space: nowrap;
                box-shadow: 0 0px 5px rgba( 0, 0, 0, 0.5 );

                -webkit-transition: all 1s ease-in-out;
                -moz-transition: all 1s ease-in-out;
                -o-transition: all 1s ease-in-out;
                -ms-transition: all 1s ease-in-out;
                transition: all 1s ease-in-out;
            }

            dd a span:after{
                border: 10px solid #F4F4F4;
                width: 0;
                height: 0;
                content: '';
                position: absolute;
                border-color: #F4F4F4 transparent transparent;
                left: 5px;
                bottom: -21px;
                opacity: 1;
            }

            dd a:hover span, dd a:focus span{
                visibility: visible;
                opacity: 1;
                top: -45px;
            }

            /***
             * Hotspot Positions
             * - replace with location to your annotations
             ***/
            dd#screenDef {
                top: 77px;
                left: 120px;
            }

            dd#screenDef a {
                width: 115px;
                height: 80px;
            }

            dd#synthDef {
                top: 180px;
                left: 225px;
            }
            dd#synthDef a {
                width: 80px;
                height: 36px;
            }

            dd#snacksDef {
                top: 220px;
                right: 159px;
            }
            dd#snacksDef a {
                width: 85px;
                height: 40px;
            }





A working example can be viewed below (the image was taken while working on our latest remix [due out soon]):
